Access Cloud Run via HTTP

Through the HTTP access service, you can configure cloud run services as standard HTTP interfaces, achieving flexible domain and path management. This document explains how to configure HTTP access for cloud run and how to use custom paths.

Prerequisites

• CloudBase environment created
• At least one cloud run service deployed

Configure HTTP Access

Step 1: Create Domain Association

1. Go to CloudBase Console - HTTP Access Service
2. Click the "New" button in the "Domain Associated Resources" section
3. Configure the following information:

Configuration Item	Description	Example
Associated Resource Type	Select "Cloud Run", then choose target cloud run service	my-service
Domain	Select default domain, custom domain, or * (matches all domains)	Default domain
Trigger Path	Set HTTP access path, supports / or custom path	/helloworld

💡 Tip: For production environments, it's recommended to bind a filed custom domain to get full service capabilities. Please refer to Custom Domain Configuration for configuration methods.

Step 2: Test Access

After configuration, access domain + trigger path to invoke the cloud run service:

# Example: Access cloud run service via default domain
curl https://your-env-id.service.tcloudbase.com/helloworld

Make HTTP Requests

After configuration, you can use any HTTP client to access cloud run services.

curl

# GET request
curl https://your-domain/helloworld

# POST request
curl -X POST https://your-domain/helloworld \
  -H "Content-Type: application/json" \
  -d '{"name": "Zhang San", "email": "zhangsan@example.com"}'

# PUT request
curl -X PUT https://your-domain/helloworld/123 \
  -H "Content-Type: application/json" \
  -d '{"name": "Li Si"}'

# DELETE request
curl -X DELETE https://your-domain/helloworld/123

JavaScript

// Using fetch API
const response = await fetch('https://your-domain/helloworld', {
  method: 'POST',
  headers: {
    'Content-Type': 'application/json'
  },
  body: JSON.stringify({
    name: 'Zhang San',
    email: 'zhangsan@example.com'
  })
});

const data = await response.json();
console.log(data);

Python

import requests

# POST request
response = requests.post(
    'https://your-domain/helloworld',
    json={'name': 'Zhang San', 'email': 'zhangsan@example.com'}
)

data = response.json()
print(data)

Cloud Run Service Development

Receive HTTP Requests

Cloud run services are standard HTTP services and can use any web framework to receive requests:

Express (Node.js)

const express = require('express');
const app = express();

// Parse JSON request body
app.use(express.json());

// GET request
app.get('/helloworld', (req, res) => {
  res.json({
    users: [
      { id: 1, name: 'Zhang San' },
      { id: 2, name: 'Li Si' }
    ]
  });
});

// POST request
app.post('/helloworld', (req, res) => {
  const { name, email } = req.body;

  res.json({
    success: true,
    user: { id: 3, name, email }
  });
});

// Start service
const PORT = process.env.PORT || 8080;
app.listen(PORT, () => {
  console.log(`Service running on port ${PORT}`);
});

Flask (Python)

from flask import Flask, request, jsonify

app = Flask(__name__)

# GET request
@app.route('/helloworld', methods=['GET'])
def get_users():
    return jsonify({
        'users': [
            {'id': 1, 'name': 'Zhang San'},
            {'id': 2, 'name': 'Li Si'}
        ]
    })

# POST request
@app.route('/helloworld', methods=['POST'])
def create_user():
    data = request.get_json()
    name = data.get('name')
    email = data.get('email')

    return jsonify({
        'success': True,
        'user': {'id': 3, 'name': name, 'email': email}
    })

# Start service
if __name__ == '__main__':
    app.run(host='0.0.0.0', port=8080)

Spring Boot (Java)

import org.springframework.boot.SpringApplication;
import org.springframework.boot.autoconfigure.SpringBootApplication;
import org.springframework.web.bind.annotation.*;

@SpringBootApplication
@RestController
@RequestMapping("/api")
public class Application {

    public static void main(String[] args) {
        SpringApplication.run(Application.class, args);
    }

    // GET request
    @GetMapping("/users")
    public Map<String, Object> getUsers() {
        List<Map<String, Object>> users = Arrays.asList(
            Map.of("id", 1, "name", "Zhang San"),
            Map.of("id", 2, "name", "Li Si")
        );
        return Map.of("users", users);
    }

    // POST request
    @PostMapping("/users")
    public Map<String, Object> createUser(@RequestBody Map<String, String> body) {
        String name = body.get("name");
        String email = body.get("email");

        return Map.of(
            "success", true,
            "user", Map.of("id", 3, "name", name, "email", email)
        );
    }
}

Gin (Go)

package main

import (
    "github.com/gin-gonic/gin"
    "net/http"
)

type User struct {
    ID    int    `json:"id"`
    Name  string `json:"name"`
    Email string `json:"email,omitempty"`
}

func main() {
    r := gin.Default()

    // GET request
    r.GET("/helloworld", func(c *gin.Context) {
        users := []User{
            {ID: 1, Name: "Zhang San"},
            {ID: 2, Name: "Li Si"},
        }
        c.JSON(http.StatusOK, gin.H{"users": users})
    })

    // POST request
    r.POST("/helloworld", func(c *gin.Context) {
        var user User
        if err := c.ShouldBindJSON(&user); err != nil {
            c.JSON(http.StatusBadRequest, gin.H{"error": err.Error()})
            return
        }

        user.ID = 3
        c.JSON(http.StatusOK, gin.H{
            "success": true,
            "user":    user,
        })
    })

    // Start service
    r.Run(":8080")
}

RESTful API Example

Express

const express = require('express');
const app = express();

app.use(express.json());

// Mock database
let users = [
  { id: 1, name: 'Zhang San', email: 'zhangsan@example.com' },
  { id: 2, name: 'Li Si', email: 'lisi@example.com' }
];

// Get all users
app.get('/helloworld', (req, res) => {
  res.json({ success: true, users });
});

// Get single user
app.get('/helloworld/:id', (req, res) => {
  const user = users.find(u => u.id === parseInt(req.params.id));

  if (!user) {
    return res.status(404).json({
      success: false,
      error: 'User not found'
    });
  }

  res.json({ success: true, user });
});

// Create user
app.post('/helloworld', (req, res) => {
  const { name, email } = req.body;

  const newUser = {
    id: users.length + 1,
    name,
    email
  };

  users.push(newUser);
  res.status(201).json({ success: true, user: newUser });
});

// Update user
app.put('/helloworld/:id', (req, res) => {
  const user = users.find(u => u.id === parseInt(req.params.id));

  if (!user) {
    return res.status(404).json({
      success: false,
      error: 'User not found'
    });
  }

  user.name = req.body.name || user.name;
  user.email = req.body.email || user.email;

  res.json({ success: true, user });
});

// Delete user
app.delete('/helloworld/:id', (req, res) => {
  const index = users.findIndex(u => u.id === parseInt(req.params.id));

  if (index === -1) {
    return res.status(404).json({
      success: false,
      error: 'User not found'
    });
  }

  users.splice(index, 1);
  res.json({ success: true, message: 'User deleted' });
});

const PORT = process.env.PORT || 8080;
app.listen(PORT, () => {
  console.log(`Server running on port ${PORT}`);
});

Flask

from flask import Flask, request, jsonify

app = Flask(__name__)

# Mock database
users = [
    {'id': 1, 'name': 'Zhang San', 'email': 'zhangsan@example.com'},
    {'id': 2, 'name': 'Li Si', 'email': 'lisi@example.com'}
]

# Get all users
@app.route('/helloworld', methods=['GET'])
def get_users():
    return jsonify({'success': True, 'users': users})

# Get single user
@app.route('/helloworld/<int:user_id>', methods=['GET'])
def get_user(user_id):
    user = next((u for u in users if u['id'] == user_id), None)

    if not user:
        return jsonify({'success': False, 'error': 'User not found'}), 404

    return jsonify({'success': True, 'user': user})

# Create user
@app.route('/helloworld', methods=['POST'])
def create_user():
    data = request.get_json()

    new_user = {
        'id': len(users) + 1,
        'name': data.get('name'),
        'email': data.get('email')
    }

    users.append(new_user)
    return jsonify({'success': True, 'user': new_user}), 201

# Update user
@app.route('/helloworld/<int:user_id>', methods=['PUT'])
def update_user(user_id):
    user = next((u for u in users if u['id'] == user_id), None)

    if not user:
        return jsonify({'success': False, 'error': 'User not found'}), 404

    data = request.get_json()
    user['name'] = data.get('name', user['name'])
    user['email'] = data.get('email', user['email'])

    return jsonify({'success': True, 'user': user})

# Delete user
@app.route('/helloworld/<int:user_id>', methods=['DELETE'])
def delete_user(user_id):
    global users
    user = next((u for u in users if u['id'] == user_id), None)

    if not user:
        return jsonify({'success': False, 'error': 'User not found'}), 404

    users = [u for u in users if u['id'] != user_id]
    return jsonify({'success': True, 'message': 'User deleted'})

if __name__ == '__main__':
    app.run(host='0.0.0.0', port=8080)
